Product Description: Epoxy resin react with the curing agent, with strong viscosity and smoothness, mainly used for the pursuit of the shaped tile, wooden board, gypsum board, aluminum plastic plate,,glass and other materials and gap decoration.
Epoxy resin:
Type |
Countertype |
Appearance |
EEW g/eq |
Viscosity 25℃mPa.s |
hydrolyzed chlorine,% |
Inorganic Chlorine,ppm |
Volatile matter,% |
Color(G) |
ER-618 |
E-51,YD128,DER331 |
Colorless liquid |
184-194 |
11500-15000 |
<0.1 |
<5 |
<0.18 |
<2 |
Epoxy hardeners:
Product name |
3688 |
3788 |
3566 |
3566-1 |
3566-3 |
3566-8 |
Appearance |
Milky white translucent paste |
|||||
Thirmetability
|
There is a thirmetability, not flowing without collapse |
|||||
Amine value(mgKOH/g)
|
200-230 |
200-230 |
200-230 |
200-230 |
200-230 |
200-230 |
Mix ratio A:B |
1:0.8-0.9 |
1:0.8-0.9 |
1:0.8-0.9 |
1:0.8-0.9 |
1:0.8-0.9 |
1:0.8-0.9 |
Handling time(40g25℃,min) |
25-45 |
25-45 |
20-40 |
15-30 |
20-40 |
20-40 |
Dry to tough(25℃,h) |
2-2.5 |
2.5-3 |
1.5-2 |
1.5-2 |
1.5-2 |
1.5-2 |
Dry through (25℃,h) |
4-5 |
4-5 |
3.5-4.5 |
3-4 |
3.5-4.5 |
3.5-4.5 |
Shore D (25℃,72h) |
70-75 |
70-75 |
70-75 |
70-75 |
70-75 |
70-75 |
Application
